• The unique stretch and retract technique avoids the bend of the core pipe and cylinder and the break of the boom caused by misoperation, improving the safety of the operations.
• Eight patent techniques ensure the smooth, high efficiency and energy conservation of the lifting, rotation, and luffing systems.
• The torque limiter adopts colorful LCD display, realizing the intelligence of the failure diagnosis. The precision is ahead of the industry.
• Adopt the new hydraulic motor with big torque starting point, making the secondary lifting safer.
• The humanity design makes the cab and control cab more spacious, and easy to operate.
• Six unique manufacturing technologies ensure the high quality.
• Extend the lifting space and scope, greatly improving the lifting capacity of the front part.
|Total weight in travel||kg||32400|
|Front axle load||kg||7000|
|Rear axle load||kg||25400|
|Engine rated power||kW/(r/min)||206/2200||213/2200|
|Engine rated torque||N.m/(r/min)||1112/1400||1160/1400|
|Max. travel speed||km/h||80|
|Min. turning diameter||m||22|
|Min. ground clearance||mm||291|
|Max. grade ability||%||40|
|Fuel consumption for 100km||L||40|
|Max. rated total lifting capacity||t||30|
|Min. rated working radius||mm||3000|
|Turning radius at turntable tail||m||3.065|
|Max. lifting torque||kN.m||1025|
|Fully extended boom||m||40.4|
|Fully extended boom+ jib||m||48.7|
|Longitudinal outrigger span||m||5.85|
|Lateral outrigger span||m||6|
|Boom luffing time||s||68|
|Boom full extension time||s||150|
|Max. swing speed||r/min||2.5|
|Max. speed of main winch (single rope) (no load)||m/min||120|
|Max. speed of aux. winch (single rope) (no load)||m/min||120|
& Due to improvements made to the product, data herein is subject to change without notice.
& Affected by the reproduction conditions, the pictures and data differ somewhat from the actual machine
